Specification Sheet:
Click to download specifications
4 Core 14/0.2 TCW
V75 insulated & V75 PVC sheathed.
Security Cable. Extra Low Voltage.
Not for mains connection.
Oxygen-Free Copper. RoHS Compliant PVC.
Construction
Conductor: 14 strands of 0.2 mm nom. Tinned Annealed Copper to AS/NZS1125 drawn from Class 102 copper to AS/NZS1574.
Max. D.C. resistance at 20C: 44.8 ohms / km.
Insulation: Coloured P.V.C to AS/NZS3808 type V75.
Nominal Diameter: 1.5 mm.
Nominal Wall Thickness: 0.26 mm.
Lay Up: 4 cores twisted
1. Black
2. White
3. Red
4. Blue
Sheath: Coloured P.V.C. to AS/NZS3808 type 4V75.
Nominal Diameter: 4.8 mm.
Nominal Wall Thickness: 0.50 mm.
Typical ropy finish.
Identification: “TYCAB NZ SECURITY SET4142 ” – at maximum 1000mm spacing.
