Specification Sheet:
Click to download specifications
3 Core 23/.32 (1.84sqmm). Tinned Copper Wire.
V90 PVC insulated. 5V90 PVC sheathed MARINE Trailer cable.
Extra Low Voltage Pleasure Craft. Not for Mains connection.
Construction
Conductor: 23 strands of 0.32mm Tinned Copper to AS/NZS 1125 drawn from Class 110A copper to AS/NZS 1574.
Max. D.C. resistance at 20C: 10.1 ohms / km.
Insulation: Coloured V90 PVC to AS/NZS 3808.
Nominal Diameter: 2.6 mm.
Nominal Wall Thickness: 0.4 mm.
Lay Up: 3 Cores laid up.
1. White
2. Yellow
3. Brown
Sheath: Coloured P.V.C. type 5V90 to AS/NZS 3808.
Nominal Diameter: 7.15 mm.
Nominal Wall Thickness: 0.6 mm.
Typical Ropy Cable finish.
Amp Rating @ 30°C: 19
| Derating Factors for Ambient Temperatures °C | |||||
| Temperature | 30 | 40 | 50 | 60 | 70 |
| Factor | 1 | 0.9 | 0.76 | 0.6 | 0.45 |
